| ELECTRICAL SPECIFICATIONS: | |
|---|---|
| FREQUENCY | 1616 - 1626.5 MHz (L-band) |
| SATELLITE SYSTEM | Iridium |
| IMPEDANCE | 50 ohm |
| POLARISATION | RHCP |
| AXIAL RATIO | < 6 dB |
| GAIN | 2 dBic |
| VSWR | < 1.5 |
| MECHANICAL SPECIFICATIONS: | |
|---|---|
| COLOR | White, non-glossy |
| HEIGHT | 188 mm, 191.5 mm including base |
| DIAMETER | 95 mm |
| MOUNTING | On flange 1"-14NF |
| OPERATING TEMPERATURE | -40C to +85C |
| CONNECTOR 1 | N (f) |
| ORDERING INFORMATION: | |
|---|---|
| PART NO. | 65000 |
| PART NO. | 65000IP (bulk) |
| PRODUCT TYPE | SATELLITE PHONE |
|---|---|
| BRAND | SCAN ANTENNA |
| PART # | 65000 |
| NETWORK | IRIDIUM |
| USAGE AREA | 100% GLOBAL |
| FEATURES | PASSIVE |
| FREQUENCY | L BAND (1-2 GHz) |
| ACCESSORY TYPE | ANTENNA |
| CERTIFICATIONS | IRIDIUM CERTIFIED |
